Managing Research Programs and Groups

Learn how to manage group research activities in Merge

Command Line and Web Based Interfaces

This walkthrough demonstrates how to manage organizations and projects using the Merge command line interface (CLI) mrg. We strive to implement equal functionality in the web-based graphical user interface (GUI), and it should possible to use the GUI rather than the CLI to manage organizations and projects. If you find that desired management functionality is missing from the GUI, please let us know by emailing us at: contact-project+mergetb-support-email@incoming.gitlab.com

Overview

The Merge Portal provides tools to facilitate management of research activities. This page discusses these tools and constructs, and gives examples of their intended use for supporting educational and research endeavors.

Merge Entities

Before discussing how to manage activities on the Portal, it is important to have a basic understanding of the key concepts and terminology that Merge uses. The following diagram illustrates the relationships between the core Merge entities:

Entity	Description
User	A user represents a human user of the Portal. Each user has a separate login username/ID, and may have membership in a set of projects and/or organizations.
Project	A project represents a type of experimental work to be done on a Merge testbed. Projects are often created to organize the activities of research groups. Users are granted membership in projects by creators and maintainers of those projects.
Organization	Organizations are used to manage a (typically large) group of users. When users join an organization, they delegate the authority to manage their account to the creators and maintainers of the organization. New users on the Portal can request membership in an organization when creating the account; when that happens, the organization’s maintainers can authorize the account without requiring approval of a Merge Portal administrator. Projects can also join organizations, which gives the organization’s maintainers access to the experiments created in that project.
Experiment	An experiment represents the target environment that a user wishes to create on the testbed. An experiment consists of a topology with nodes and links and characteristics of the topology, including OS images and link rates. Experiments are created in the context of a specific project.
Realization	A realization is a logical creation of an experiment on an underlying Merge testbed. When an experiment is successfully realized, the resulting realization is an embedding of the experiment topology on the physical resources of one or more resource substrates managed by the Merge Portal. Resources are reserved for the exclusive use of the realization, until the realization is relinquished by the user.
Materialization	A materialization is a physical instantiation of a realization on the resource substrates. When a materialization is created, virtual machine and bare metal nodes are imaged with OSes, and virtual networks are synthesized on node and switches to create the requested experiment topology.
Testbed Node	A testbed node is a physical server or device that is used to run experiment materializations.
Resource Pool	A resource pool, or simply pool, is a set of testbed nodes. Each project belongs to a pool. When experiments in a project are realized, the Portal realization algorithm may allocate nodes from the pool. Multiple pools can be created by Merge Portal administrators, thereby partitioning/reserving resources for use in different projects.
XDC	Experiment Development Containers, or XDCs, are lightweight containers that provide users access to materializations through use of on-demand VPN tunnels. XDCs are created by users in the context of a specific project, and then attached to a materialization, which creates a VPN tunnel between the XDC and the infranet of the materialization. XDCs can themselves be accessed from the user’s workstation, either through SSH or via the Launch web GUI.

Managing Organizations

Organizations are designed to facilitate management of large groups of users (typically tens to hundreds) by a small privileged set of users called organization maintainers. Organizations can be created by users with a demonstrated need to manage a large group. Typically organizations are created to manage large government funded research programs, where a large group of users collaborating on the same sets of projects are expected to join the Portal.

Creating an Organization

A new organization can be created via the CLI’s mrg new organization command:

$ mrg new organization -h
Create a new organization

Usage:
  mrg new organization <name> [flags]

Flags:
  -d, --desc string   organization description
  -h, --help          help for organization
  -m, --mode enum     Access mode: one of public, private, protected. Default: public

Global Flags:
  -c, --colorless         Disable color output
  -j, --json              Output JSON
  -l, --loglevel string   Level to log at. One of panic, fatal, error, warning, info, debug, trace (default "info")
  -s, --server string     MergeTB API server address

Note the -d flag, which provides a description for the organization. This command creates an organization, but places it a temporary inactive state. This is done because organization maintainers are considered trusted users, given their ability to directly approve new accounts on the Portal. Users who believe they have a legitimate use case to run an organization – e.g., they lead a large research group – should reach out to the Merge Portal operators to have their organization approved and placed in an active state.

Having Your Organization Activated

Organization maintainers have a high level of privilege: when new members join their organization, portal accounts for those members are automatically activated, without involvement of Merge portal operators. This design facilitates quick standup of new organizations and influxes of new members, but it places a large degree of confidence in organization maintainers, who must be responsible to only approve membership for users with a need for testbed use, and to freeze accounts of users that no longer have an authorized need for testbed use – for example, for users that violate terms of service or abuse resources.

Once you have created an organization, please send a message to the Merge portal operators via the support email contact-project+mergetb-support-email@incoming.gitlab.com, providing a justification for your organization. If portal operators approve of your use case, they will activate your organization, at which point you can admit new members and create projects.

Requesting Membership

Organization membership starts by a user making a request to join the organization. Typically, a user’s organization membership will be requested by the user itself; however, membership for the user can also be requested by an existing maintainer on behalf of the user.

Organization membership can be requested through the CLIs’ mrg membership request organization user <organization> <username> command:

$ mrg membership request organization user -h
Request a user membership in an organization

Usage:
  mrg membership request organization user [organization] [username] [flags]

Flags:
  -h, --help          help for user
  -r, --role string   One of Member, Maintainer, Creator (default "Member")

Global Flags:
  -c, --colorless         Disable color output
  -j, --json              Output JSON
  -l, --loglevel string   Level to log at. One of panic, fatal, error, warning, info, debug, trace (default "info")
  -s, --server string     MergeTB API server address

Note the -r flag: each user in an organization must be assigned a Role. The role determines what privileges the user has with respect to operations that read or modify organization state, as described in this table:

Role	Description
Creator	The user that created the organization. This user has full privileges to modify the organization and admit members as needed
Maintainer	A user that is fully authorized to manage the organization. Maintainers typically have the same privileges as the creator
Member	A user that is a member of the organization, thereby having access to its projects, but whom does not have privilege necessary to approve accounts or add/remove members

By default, requests are made for the Member role.

Confirming or Denying Membership

Organization membership is contingent on approval by both the candidate new user and a maintainer of the organization. If a user requests their own membership, they tacitly provide approval, meaning only maintainer approval is needed to confirm membership. Conversely, if a maintainer requests membership on behalf of a user, they tacitly approve membership, but the user must confirm the request in order to be added to the organization. Note that these two approvals can happen in either order. That is, the user can request membership and then be approved by a maintainer, or a maintainer can add the user, and the user can subsequently approve their addition. The following state diagram illustrates the process:

Remember: Organization Membership Requires 2 Approvals

Keep in mind that becoming an Active member of an organization requires approval from both (1) the user being added to the organization, and (2) an organization creator or maintainer. If only one of the two approves, the user will be in either the EntityRequested or MemberRequested states, which are pending states: the user will not be considered a member, will not have access to projects or other data in the organization, and their account will not be able to be managed by the organization maintainers.

To confirm or deny membership, use the CLIs’ mrg membership confirm or mrg membership deny commands. To confirm:

$ mrg membership confirm organization user -h
Confirm a user in an organization

Usage:
  mrg membership confirm organization user <organization> <username> [flags]

Flags:
  -h, --help   help for user

Global Flags:
  -c, --colorless         Disable color output
  -j, --json              Output JSON
  -l, --loglevel string   Level to log at. One of panic, fatal, error, warning, info, debug, trace (default "info")
  -s, --server string     MergeTB API server address

To deny:

$ mrg membership deny organization user -h
Deny a user membership in an organization

Usage:
  mrg membership deny organization user <organization> <username> [flags]

Flags:
  -h, --help   help for user

Global Flags:
  -c, --colorless         Disable color output
  -j, --json              Output JSON
  -l, --loglevel string   Level to log at. One of panic, fatal, error, warning, info, debug, trace (default "info")
  -s, --server string     MergeTB API server address

Removing Members

After a member has been confirmed, either an organization maintainer or the member themself can remove the member at any time. Use the same mrg membership deny command as above to do so.

Deactivating Accounts

When an organization maintainer approves a new member, the Merge portal account for the new member becomes fully activated. In this way, organization maintainers have a very high level of privilege: the accounts they approve are activated without explicit approval of a Merge portal operator.

When an organization member no longer has an authorized need for testbed use, organization maintainers should deactivate or “freeze” the member’s account. This can be done through the following CLI command:

$ mrg freeze user -h
Freeze a user

Usage:
  mrg freeze user <username> [flags]

Flags:
  -h, --help   help for user

Global Flags:
  -c, --colorless         Disable color output
  -j, --json              Output JSON
  -l, --loglevel string   Level to log at. One of panic, fatal, error, warning, info, debug, trace (default "info")
  -s, --server string     MergeTB API server address

If the maintainer wishes, they can then remove the user from the organization.

Managing Projects

Projects are designed to facilitate management of small groups of users (typically tens or fewer) that intend to collaborate on a set of experiments. Projects can be created by users with an authorized need for testbed resources. Typically, projects are created to manage small research projects involving a research advisor and a set of students and/or collaborators; however, this is not a requirement. Any academic research activity with a valid use case can be represented by a project.

Projects are simpler to manage than organizations. Project creators/maintainers do not admit new users to the testbed, and do not have authority to activate or freeze accounts. Project maintainers simply have the authority to add new members that already have portal accounts to the project, thereby giving those users access to testbed resources via the project, as well as access to existing experiments already created in the project namespace.

Creating a Project

A new project can be created via the CLI’s mrg new project command:

$ mrg new project -h
Create a new project

Usage:
  mrg new project <name> <description> [flags]

Flags:
  -h, --help                  help for project
  -o, --organization string   add the project be added to the given organization

Global Flags:
  -c, --colorless         Disable color output
  -j, --json              Output JSON
  -l, --loglevel string   Level to log at. One of panic, fatal, error, warning, info, debug, trace (default "info")
  -s, --server string     MergeTB API server address

The project requires both a name and a description as command line arguments. The description is important, as Merge portal operators will use it to determine whether the project’s efforts constitute a valid use case for the testbed.

Acquiring Resources

Once a project has been created, you will be able to add members to the project, create experiments, and realize/materialize those experiments.

However, at this stage, the amount of resources on the testbed that your project can use may be limited. As discussed in the Merge Entities section, each project is a member of a resource pool, and by default, projects are placed into a default pool that is usually configured with a limited number of testbed nodes, sufficient only to create small experiments and play around with the testbed. To acquire access to more resources, you should open a ticket to request Merge operators to place you in a larger resource pool. Please send a message to the Merge portal operators via the support email contact-project+mergetb-support-email@incoming.gitlab.com, providing the name of your project in the message.

Note, however, that organization projects are treated differently. If you are a member of an organization, you can use the -o flag for the mrg new project command to associate the project with the organization. When you do this, the project will automatically use any resource pools that may have been created for the organization. If you do not add your project to an organization, you will be responsible for getting access to a resource pool, which must be done in consultation with Merge portal operators as discussed in the previous paragraph.

Personal Projects

Note that all users have a personal project automatically created for them when their account is activated on the Merge portal. Personal projects have the same name as the username of the owning user. For example, user bob’s personal project is named bob. Note that personal projects do not exist in the context of any organization, even if the user requests organization membership at account creation.

Personal projects are meant for simple experimentation and exploration of the testbed. They should not be used for complex experiments or experiments requiring more than a limited amount of resources.

Adding or Removing Members

Unlike organizations, membership in projects simply requires that an authorized project owner or maintainer add a valid user account. This is done via the CLI command mrg new member project:

$ mrg new member project -h
Add a user to a project

Usage:
  mrg new member project <project> <username> [flags]

Flags:
  -h, --help          help for project
  -r, --role string   One of Member, Maintainer, Creator (default "Member")

Global Flags:
  -c, --colorless         Disable color output
  -j, --json              Output JSON
  -l, --loglevel string   Level to log at. One of panic, fatal, error, warning, info, debug, trace (default "info")
  -s, --server string     MergeTB API server address

As with organizations, project members are assigned a Role via the -r flag:

Role	Description
Creator	The user that created the project. This user has full privileges to modify the project and add/remove members as needed
Maintainer	A user that is fully authorized to manage the project. Maintainers typically have the same privileges as the creator
Member	A user that is a member of the project, thereby having access to its experiments, but whom does not have privilege necessary to manage the project and add/remove members

Use Case 1: Small Research Lab

Use case 1 focuses on the activities of a small research lab. In this case, an organization is overkill. The principal investigator (PI) for the group should instead simply create a project. The PI can then add students or other members of the lab as Maintainers of the project. The PI or project maintainers can then add other collaborators as regular Members. Upon creating the project, the PI or a maintainer of the project should submit a ticket via the support email contact-project+mergetb-support-email@incoming.gitlab.com to have their project placed into a resource pool with sufficient nodes to support the project activities.

We summarize the process below:

All members from the research group create accounts through the Merge portal. These accounts will be approved by Merge portal operators, as there is no governing organization involved.
The PI creates a project, adding a ~1 paragraph description of the project’s anticipated research activities and the types of experiments that will be performed.
The PI or a maintainer of the project submits a ticket via the support email to have their project placed into a resource pool with sufficient nodes to support the project activities.
The PI adds other group members to the project, assigning them each the role of Maintainer or Member, depending on the level of privilege desired for each user. See the table in #Adding or Removing Members for a description of project roles. Note that a Maintainer may also add additional members to the project.
Project members create, realize, and materialize experiments on the testbed.

Use Case 2: Large Research Program

Our second use case focuses on the activities of a larger scale research program, such as those involving multiple individually funded research performers working towards a common research objective. In this case, a designated “program coordinator” (could be the program manager, PI of a funded project, or a Merge portal operator, etc.) creates the organization and has it approved by Merge operators. PIs of each individual funded project join the organization as Maintainers, and create individual projects within the organization to manage the efforts of their team/group. Individual contributors to each team join the organization as regular Members and are assigned to the specific project by their project PI. Organizations facilitate a flexible managerial model: the program coordinator need only create the organization and approve accounts of the project PIs, who in turn approve accounts of organization members that belong to their team. The activities of each team are localized to their specific project. Each project can be created with specific permissions to either allow or disallow access to non-project members.

One example breakdown of roles and activities in a research organization is shown below, involving three research projects collaborating in a research program.

We summarize the process below:

Program coordinator creates an account through the Merge portal. This account will be approved by a Merge portal operator.
Program coordinator creates an organization for the research program, describing the nature of organization as supporting a funded research program, and emails the Merge portal operators to request activation.
Individual project PIs create accounts on the Merge portal and request membership in the organization, selecting the Maintainer role, and contact program coordinator to request approval of their organization membership.
Project PIs create projects for their specific team’s work, creating the project in the context of the organization.
Team members create accounts on the Merge portal and request a regular Member roll in the organization. Project PIs approve accounts as needed, and add team members to their respective projects with the desired role for the project.
Project members create, realize, and materialize experiments on the testbed.
